Probecom's SSPA & TWTA Series

Probecom SSPA & TWTA adopts latest technology, providing ultimate performance in high frequency and ultrabandwith. Widely used in satellite communication ground station, data link, measurement and control, electronic warfare and other fields. And suitable for envirement such as ground, carrier, airborne, etc.

Products integrated monitoring system, power supply system and cooling system. Built in monitoring system provide forward / echo output power detection, temperature detection, remote switch machine, over temperature protection, VSWR protection, real-time monitoring of power amplifier voltage and current function. Monitoring system can communicated with terminal computer through serial port RS485/422/LNA, all test data are displayed on the computer terminal in real time.

Both SSPA & TWTA can be customized according to customer requirements.

a

* Ultra-wideband CW SSPA System

* PW / CW SSPA System

* Q,V,W SSPA Available

* 1:1,1:2 Redundancy Configuration

* Special Customer Order

Operating Frequency Range	Output Power
L: 1GHz-2GHz	10KW
S: 2GHz-4GHz	10KW
C: 4GHz-8GHz	8KW
X: 8GHz-12GHz	8KW
Ku: 12GHz-18GHz	6KW
K: 18GHz-26GHz	1KW
Ka: 26GHz-40GHz	1KW
V: 59GHz-64GHz	200W
W: 92GHz-96GHz	100W
S/C: 2GHz-6GHz	300W
C/X/Ku: 6GHz-18GHz	200W
S/C: 2GHz-8GHz	200W
X/Ku:8GHz-18GHz	2KW

Contact:

sales@probecom.cn

sales@probecom.com

Shaanxi Probecom Microwave Technology Co.,LTD (abbreviated as Probecom), was founded in 2002, located in International Trade and Logistic Park in Xi’an, we are mainly engaged in the design and manufacture of all types of satellite communication Earth Station Antenna, VSAT Antenna, Ka Series Antenna, Portable Flyaway Antenna, RxO/TVRO Antenna, SNG Antenna, On-the-Move Antenna, Remote Sensing & Telemetry Antenna, Meteorological Radars, High Power and Ultra Wideband Amplifiers (SSPA & TWTA), Microwave Components as well as the related Antenna Control & Tracking System.
